10.3 RULED SURFACE (Cycle 231, DIN/ISO: G231)
10
242
TNC 640 | User's Manual Cycle Programming | 3/2014
Number of cuts Q240: Number of passes to be
made between points 1 and 4, 2 and 3. Input range
0 to 99999
Feed rate for milling Q207: Traversing speed of the
tool in mm/min while milling. The TNC performs the
first step at half the programmed feed rate. Input
range 0 to 99999.999, alternatively FAUTO, FU, FZ
Q236=+25 ;4TH POINT 3RD AXIS
Q240=40 ;NUMBER OF CUTS
Q207=500 ;FEED RATE FOR
MILLING
